Details

---

Vernier Depth Calipers With Single Hook
Series 322

FEATURES

• Resolution: .001'' / 0.05mm
• The stationary measuring surface on the beam protrudes at right angles (measuring hook) to allow for the measurement of depths, internal groove positions, and other intricate characteristics
• Measurements can be taken on either side of the measuring hook
• Vernier models are designed allowing the main beam to be reversible with corresponding scales on the slider
• All measuring surfaces are hardened

STANDARD ACCESSORIES

• Warranty card, Calibration Certificate, Instruction manual

Mechanical Models
Range	Graduation	Accuracy	Code No.
0-150mm / 0-1''	0.05mm	± 0.05mm	322-06-2
0-200mm / 1-2''	0.05mm	± 0.05mm	322-08-2
0-300mm / 2-3''	0.05mm	± 0.08mm	322-12-2
