Details

---

AGD1 Dial Indicators
Series 401

FEATURES

• Graduation:
  Inch: .0005'' / .001''
  Metric: 0.01mm
• Dial face dia.: Ø1.61'' / Ø42mm
• Jeweled
• Flat back (attached) and lug back supplied
• Inch models without revolution counter

STANDARD ACCESSORIES

• Flat back
• Warranty card, Calibration certificate, Instruction manual

Stem Dia. Ø3/8''
Range	Graduation	Range / Rev.	Dial Reading	Accuracy	Code No.
0-3mm	0.01mm	0.5mm	0-50	± 0.010mm	401-03-1
0-5mm	0.01mm	0.5mm	0-50	± 0.012mm	401-05-1
Stem Dia. Ø8mm
Range	Graduation	Range / Rev.	Dial Reading	Accuracy	Code No.
0-3mm	0.01mm	0.5mm	0-50	0.014mm	401-03-0
0-5mm	0.01mm	0.5mm	0-50	0.016mm	401-05-0
0-5mm	0.01mm	0.5mm	0-25-0	0.016mm	401-05-2
